raplas SLA Materials

Raplas offer a completely open unlocked 355nm open stereolithography system with performance attributes that lead the market. Alongside our machines we offer materials capable of maximising the performance of our systems with unique benefits of tuned capabilities. Raplas are proud to work alongside the major global manufacturers of materials and can provide systems for use with all commercial resins operating at the 355nm wavelength.

Raplas RR60CR

RR60CR is a crystal clear, tough dimensionally stable resin for 355nm Solid State Laser Systems.

Ideal for high clarity and dimensionally challenging builds. Its low viscosity with excellent re-wetting provide fast stunning clear parts for industrial applications.



General Properties

  • Colour: Crystal Clear
  • Viscosity: 270 cps
  • Ec: 11.2 mj/cm2
  • Dp: 6.6 mils
  • Density: 1.12 g/cm3

data sheet

RAPLAS RR60wh

RR60WH is a tough optically neutral white, dimensionally stable resin for 355nm Solid State Laser Systems.

Ideal for general purpose and detail critical builds. Its low viscosity with excellent re-wetting provide fast build times increasing productivity.

General Properties

  • Colour: White

  • Viscosity: 290 cps
  • Ec: 10.6 mj/cm2
  • Dp: 6.6 mils
  • Density: 1.12 g/cm3
  • Tensile Strength: ASTM D638 54Mpa
  • Tensile Modulus: ASTM D638 2920Mp



data sheet

RAPLAS RR60GR

RR60GR is a tough neutral pale grey resin for 355nm Solid State Laser Systems.

Ideal for general purpose and fine detail parts. Its low viscosity with excellent re-wetting provide fast build times increasing productivity.

General Properties

  • Colour: Grey

  • Viscosity: 290 cps
  • Ec: 10.6 mj/cm2
  • Dp: 6.6 mils
  • Density: 1.12 g/cm3
  • Tensile Strength: ASTM D638 54Mpa
  • Tensile Modulus: ASTM D638 2920Mp
data sheet

RAPLASprint bio

RaplasPrint Bio is a BPA-Free, tough, dimensionally stable resin for 355nm Solid State Laser Systems.

Ideal for the maunfacture of medical devices, hearing-aids, drill-guides and other applications requiring medical conformity. Other colors available upon request.

General Properties

  • Colour: Clear

  • Viscosity: 1760 cps
  • Ec: 18.5 mj/cm2
  • Dp: 6.9 mils
  • Density: 1.1 g/cm3
  • Cured Hardness: ASTM D2240 83 Shore D
  • Flextural Strength: ASTM D790 84Mpa

Medical Conformity

  • Medical Devices – 93/42/EEC  – Class IIa, R5, S2

  • Biological – ISO 10993 – Part 1/5/10

    Bisophenol A – BPA – BPA Free

    Post-processing: Pre-cleaning with isopropanol for 3 mins in an ultrasonic bath, venting canals with compressed air, main-cleaning with isopropanol for 3 mins in an ultrasonic bath, blowing off the remaining isopropanol and drying for 30 mins at approx. 40°C. Post-curing: Standard UV Post Curing Unit or Xenon Photoflash Unit.

data sheet

RAPLAS R100DC

R100DC is a direct casting  resin for 355nm Solid State Laser Systems.

Ideal for high detail investment patterns with good surface finish capable of detailed parts. R100DC has a low melt temperature and produces a clean burning pattern with good natural strength. Cured resin is stable and resists attack from investment and shell materials before burnout.

General Properties

  • Colour: Lime Green

  • Viscosity: 200 cps
  • Ec: 10.6 mj/cm2
  • Dp: 6.6 mils
  • Density: 1.12 g/cm3
  • Tensile Strength: ASTM D638 51MPa
  • Tensile Modulus: ASTM D638 2650MPa
data sheet
